ST LV

Level transmitter

✔ EMC immunity: as per EN 61326.

Industrial sector:
  • Water treatment
Instrument type:
  • Submersible pressure transmitters
Specific applications:
  • Viscous fluids
  • Sedimentous fluids
Conformity:
  • Directive PED 2014/68/UE
  • Directive RoHS 2011/65/UE
  • Directive EMC 2014/30/UE
  • EAC Conformity
Function:
  • Transmitter
Accuracy:
  • 0,5 of FSV
Material:
  • All Stainless steel
Range:
  • 0...0,1 / 0...25bar
Sensing element:
  • Piezoresistive and ceramic sensor
Protection degree:
  • Submersible
Process connection material:
  • AISI 316 L
Sensing element material:
  • AISI 316 L, Ceramic
Output signal:
  • 4...20mA
Name Type Download
Data Sheet STLV Data sheetitenesptdefrru
User Guide STLV Manualitenesfr
PED-EMC-RoHS Conformityiten
RoHS Conformityiten
